Name: Дънна платка, ASROCK Z890 PRO-A
Brand: ACER
SKU: Z890 PRO-A
Price: 172.68 EUR
Availability: InStock

☎ 0886 177 222 ✉ info@xtreme.bg

Доставка· Условия· Рекламация· Контакти·

Вход

⇆Сравни ⚙Сглоби PC Количка

ACER

Цена

€172⁶⁸ / 337⁷³ лв

с ДДС

* ВЪНШЕН ДОСТАВЧИК - (1 до 3 дни)

* - Стоката е в склад на официалния вносител на марката за България. Времето за доставка е обикновено от 1 до 3 работни дни. Възможно е към момента на завършване на поръчката, продукта да е вече изчерпан. В случай на изчерпана наличност ще се свържем с Вас

К-во:

Добави в Количката

Удължи гаранцията си

+1 година: + 23€

+2 години: + 33€

Код: Z890 PRO-A
Категория: Дънни Платки
Гаранция: 3 Години

РЕЙТИНГ

ТВОЯ РЕЙТИНГ

Мнения

Информираме Ви, че въпреки нашите усилия не можем да гарантираме, че публикуваната информация и снимки не съдържат неточности или грешки, които не могат да бъдат правно основание за претенции.

Описание
Детайли
Мнения
ИИ Описание

Vendor_url

https://www.asrock.com/mb/Intel/Z890%20Pro-A/index.asp

Graphics

- Intel® Xe LPG Graphics Architecture

- 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz

- 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz

- 1 x Intel® Thunderbolt™ 4, supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz

Chipset

Intel® Z890

Expansion slots

CPU

- 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode

Chipset

- 2 x PCIe 4.0 x4 Slots (PCIE3 and PCIE4), support x4 mode

- 1 x PCIe 4.0 x1 Slot (PCIE2)

- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVio/CNVio2 (Integrated WiFi/BT)

Storage

CPU

- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode

- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode

Chipset

- 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode

- 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2230/2242/2260/2280 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes

- 4 x SATA3 6.0 Gb/s Connectors

- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices

Memory type

- Dual Channel DDR5 Memory Technology

- 4 x DDR5 DIMM Slots

- Supports DDR5 non-ECC, un-buffered memory up to 9066MHz+(OC)*

- Supports Clocked Unbuffered DIMM (CUDIMM)

- Max. capacity of system memory: 256GB

- Supports Intel® Extreme Memory Profile (XMP) 3.0x

Rear panel I/O

CPU

- 1 x Thunderbolt™ 4 Type-C (Rear)

- 1 x USB 3.2 Gen2x2 Type-C (Rear) Chipset:

- 1 x USB 3.2 Gen2x2 Type-C (Front)

- 1 x USB 3.2 Gen2 Type-A (Rear)

- 6 x USB 3.2 Gen1 (2 Rear, 4 Front)

- 8 x USB 2.0 (4 Rear, 4 Front)

- 2 x Antenna Mounting Points

- 1 x HDMI Port

- 1 x DisplayPort 1.4

- 1 x Thunderbolt™ 4 Type-C Port (40 Gb/s for USB4 protocol

40Gb/s for Thunderbolt™ protocol)*

- 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)

- 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s)

- 2 x USB 3.2 Gen1 Ports

- 4 x USB 2.0 Ports

- 1 x RJ-45 LAN Port

- 1 x BIOS Flashback Button

- HD Audio Jacks: Line in / Front Speaker / Microphone

Connectors

- 1 x SPI TPM Header

- 1 x Power LED and Speaker Header

- 1 x RGB LED Header

- 3 x Addressable LED Headers

- 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control)

- 5 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)

- 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)

- 1 x 24 pin ATX Power Connector

- 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)

- 1 x Front Panel Audio Connector

- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

- 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)

- 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)

Audio

7.1 CH HD Audio (Realtek ALC897 Audio Codec)

Lan

- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s

- Dragon RTL8125BG

- Supports Dragon 2.5G LAN Software

- Smart Auto Adjust Bandwidth Control

- Visual User Friendly UI

- Visual Network Usage Statistics

- Optimized Default Setting for Game, Browser, and Streaming Modes

- User Customized Priority Control

BIOS

256Mb AMI UEFI Legal BIOS with GUI support

Form factor

- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm

- 2oz Copper PCB

Microsoft Windows® 11 64-bit

Software

- ASRock Motherboard Utility (A-Tuning)

- ASRock Dragon 2.5G LAN Software

- ASRock Polychrome SYNC

UEFI

- ASRock EZ Mode

- ASRock Full HD UEFI

- ASRock My Favorites in UEFI

- ASRock Auto Driver Installer

- ASRock Instant Flash

Warranty

36 Months

Данни, подадени от официалния вносител за България.

Атрибут	Стойност
Vendor_url	https://www.asrock.com/mb/Intel/Z890%20Pro-A/index.asp
Chipset	Intel® Z890
OS	Microsoft Windows® 11 64-bit
OS	Software
OS	- ASRock Motherboard Utility (A-Tuning)
OS	UEFI
OS	- ASRock Full HD UEFI
OS	- ASRock Auto Driver Installer
OS	- ASRock Instant Flash
OS	- ASRock Dragon 2.5G LAN Software
OS	- ASRock Polychrome SYNC
OS	- ASRock EZ Mode
OS	- ASRock My Favorites in UEFI
Warranty	36 Months
CPU's supported	- Supports Intel® Hybrid Technology
CPU's supported	- Supports Intel® Turbo Boost Max 3.0 Technology
CPU's supported	- Supports Intel® Thermal Velocity Boost (TVB)
CPU's supported	- Supports Intel® Adaptive Boost Technology (ABT)
CPU's supported	- Supports Intel® Core™ Ultra Processors (Series 2) (LGA1851RL-ILM)
CPU's supported	- Integrated NPU for dedicated AI acceleration
Memory type	- Dual Channel DDR5 Memory Technology
Memory type	- 4 x DDR5 DIMM Slots
Memory type	- Max. capacity of system memory: 256GB
Memory type	- Supports DDR5 non-ECC, un-buffered memory up to 9066MHz+(OC)*
Memory type	- Supports Clocked Unbuffered DIMM (CUDIMM)
Memory type	- Supports Intel® Extreme Memory Profile (XMP) 3.0x
Form Factor	- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
Form Factor	- 2oz Copper PCB
Audio	7.1 CH HD Audio (Realtek ALC897 Audio Codec)
Rear panel I/O	- 1 x HDMI Port
Rear panel I/O	- HD Audio Jacks: Line in / Front Speaker / Microphone
Rear panel I/O	- 1 x DisplayPort 1.4
Rear panel I/O	- 2 x Antenna Mounting Points
Rear panel I/O	- 1 x RJ-45 LAN Port
Rear panel I/O	- 1 x BIOS Flashback Button
Rear panel I/O	- 4 x USB 2.0 Ports
Rear panel I/O	- 2 x USB 3.2 Gen1 Ports
Rear panel I/O	- 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s)
Rear panel I/O	CPU
Rear panel I/O	- 1 x USB 3.2 Gen2x2 Type-C (Front)
Rear panel I/O	- 8 x USB 2.0 (4 Rear, 4 Front)
Rear panel I/O	- 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)
Rear panel I/O	- 1 x Thunderbolt™ 4 Type-C (Rear)
Rear panel I/O	- 1 x USB 3.2 Gen2x2 Type-C (Rear) Chipset:
Rear panel I/O	- 1 x USB 3.2 Gen2 Type-A (Rear)
Rear panel I/O	- 6 x USB 3.2 Gen1 (2 Rear, 4 Front)
Rear panel I/O	- 1 x Thunderbolt™ 4 Type-C Port (40 Gb/s for USB4 protocol
Rear panel I/O	40Gb/s for Thunderbolt™ protocol)*
LAN	- 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
LAN	- Dragon RTL8125BG
LAN	- Supports Dragon 2.5G LAN Software
LAN	- Smart Auto Adjust Bandwidth Control
LAN	- Visual User Friendly UI
LAN	- Visual Network Usage Statistics
LAN	- Optimized Default Setting for Game, Browser, and Streaming Modes
LAN	- User Customized Priority Control
Expansion Slots	CPU
Expansion Slots	Chipset
Expansion Slots	- 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode
Expansion Slots	- 1 x PCIe 4.0 x1 Slot (PCIE2)
Expansion Slots	- 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVio/CNVio2 (Integrated WiFi/BT)
Expansion Slots	- 2 x PCIe 4.0 x4 Slots (PCIE3 and PCIE4), support x4 mode
Graphics	- 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
Graphics	- 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
Graphics	- 1 x Intel® Thunderbolt™ 4, supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
Graphics	- Intel® Xe LPG Graphics Architecture
Features	Superb Productivity
Features	- Dual Channel DDR5
Features	Rock-Solid Durability
Features	EZ Update
Features	- BIOS Flashback Button
Features	- ASRock Auto Driver Installer
Features	EZ Troubleshooter
Features	Ultrafast Connectivity
Features	- PCIe Gen5 (Graphics, M.2)
Features	- 2.5G LAN
Features	- Thunderbolt™ 4 Type-C Port (40 Gb/s)
Features	- Memory OC Shield
Features	- 16+1+1+1+1 Power Phase, Dr. MOS for VCore+GT
BIOS	256Mb AMI UEFI Legal BIOS with GUI support
I/O	- 1 x HDMI Port
I/O	- HD Audio Jacks: Line in / Front Speaker / Microphone
I/O	- 1 x DisplayPort 1.4
I/O	- 2 x Antenna Mounting Points
I/O	- 1 x RJ-45 LAN Port
I/O	- 1 x BIOS Flashback Button
I/O	- 4 x USB 2.0 Ports
I/O	- 2 x USB 3.2 Gen1 Ports
I/O	- 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s)
I/O	- 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)
I/O	CPU
I/O	- 1 x USB 3.2 Gen2x2 Type-C (Front)
I/O	- 8 x USB 2.0 (4 Rear, 4 Front)
I/O	- 1 x Thunderbolt™ 4 Type-C (Rear)
I/O	- 1 x USB 3.2 Gen2x2 Type-C (Rear) Chipset:
I/O	- 1 x USB 3.2 Gen2 Type-A (Rear)
I/O	- 6 x USB 3.2 Gen1 (2 Rear, 4 Front)
I/O	- 1 x Thunderbolt™ 4 Type-C Port (40 Gb/s for USB4 protocol
I/O	40Gb/s for Thunderbolt™ protocol)*
Storage	- 4 x SATA3 6.0 Gb/s Connectors
Storage	CPU
Storage	Chipset
Storage	- 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode
Storage	- 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode
Storage	- 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode
Storage	- 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2230/2242/2260/2280 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes
Storage	- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Storage	- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices
Connectors	- 1 x Power LED and Speaker Header
Connectors	- 1 x 24 pin ATX Power Connector
Connectors	- 1 x Front Panel Audio Connector
Connectors	- 1 x SPI TPM Header
Connectors	- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
Connectors	- 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
Connectors	- 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
Connectors	- 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)
Connectors	- 1 x RGB LED Header
Connectors	- 3 x Addressable LED Headers
Connectors	- 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control)
Connectors	- 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)
Connectors	- 5 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)
Тегло	1.22кг

Данни, автоматично извлечени от интернет. Точността не е гарантирана. За подробна информация, моля, свържете се с нас или посетете страницата на производителя.

Атрибут	Стойност
Сокет	LGA1851
Форм фактор	ATX
Чипсет	Intel Z890
Тип памет	DDR5
Слотове за памет (count)	4
Максимална памет (GB)	256
M.2 слотове (count)	4
SATA портове (count)	6
PCIe x16 слотове (count)	2
Вграден Wi-Fi	Wi-Fi 7
Скорост на LAN	2.5 Gbps
USB-C портове (count)	2
RGB подсветка	Да
Тегло	1.22кг

Дънна платка ASRock Z890 PRO-A

Освободете пълния потенциал на процесорите Intel Core Ultra с дънната платка ASRock Z890 PRO-A. Създадена за геймъри и творци, тя предлага мощно захранване, свързаност от ново поколение и безупречна многозадачност.

Ключови Предимства

Производителност от ново поколение — Поддържа Intel Core Ultra процесори с цокъл LGA1851 и DDR5 памет за изключителна скорост.
Разширена свързаност — Включва PCIe 5.0, USB-C и 2.5 GbE LAN за бърз трансфер на данни и мрежова връзка.
Подобрено охлаждане — Цялостен дизайн с радиатори и хедъри за вентилатори, които поддържат системата хладна при натоварване.

Технически Спецификации

Спецификация	Стойност
Цокъл	LGA1851
Форм фактор	ATX
Чипсет	Intel Z890
Тип памет	DDR5
Слотове за памет	4
Максимална памет	256 GB
M.2 слотове	4
SATA портове	6
PCIe x16 слотове	2
Вграден Wi-Fi	Wi-Fi 7
Скорост на LAN	2.5 Gbps
USB-C портове	2
RGB подсветка	Да
