Switch, HPE Networking Instant On Switch 24p Gigabit CL4 PoE 4p SFP+ 195W 1930

The HPE Networking Instant On 1930 24G Class4 PoE 4SFP/SFP+ 195W Switch is designed to meet the demands of modern businesses, offering a powerful combination of performance, security, and manageability. This rack-mountable switch features 24 PoE ports and 4 SFP+ ports, providing high-speed connectivity and flexibility for a variety of networking devices. With a switching capacity of 128 Gbps and support for jumbo frames up to 9,216 bytes, it ensures efficient data traffic flow and minimal latency. Advanced security features, including Access Control List (ACL) support, RADIUS authentication, and SSL encryption, protect your network from unauthorized access. The switch is also manageable via multiple protocols, including HTTP, HTTPS, SNMP, and RMON, allowing for easy configuration and monitoring. Its compliance with a wide range of environmental and safety standards, along with an impressive MTBF of 76 years, ensures reliability and durability in challenging operational environments. Whether you're upgrading an existing network or building a new one, the HPE Networking Instant On 1930 switch is a reliable choice that offers both high performance and peace of mind.

Description
Marketing Description	The HPE Networking Instant On 1930 24G Class4 PoE 4SFP/SFP+ 195W Switch is designed to meet the demands of modern businesses, offering a powerful combination of performance, security, and manageability. This rack-mountable switch features 24 PoE ports and 4 SFP+ ports, providing high-speed connectivity and flexibility for a variety of networking devices. With a switching capacity of 128 Gbps and support for jumbo frames up to 9,216 bytes, it ensures efficient data traffic flow and minimal latency. Advanced security features, including Access Control List (ACL) support, RADIUS authentication, and SSL encryption, protect your network from unauthorized access. The switch is also manageable via multiple protocols, including HTTP, HTTPS, SNMP, and RMON, allowing for easy configuration and monitoring. Its compliance with a wide range of environmental and safety standards, along with an impressive MTBF of 76 years, ensures reliability and durability in challenging operational environments. Whether you're upgrading an existing network or building a new one, the HPE Networking Instant On 1930 switch is a reliable choice that offers both high performance and peace of mind.
General
Device Type	Switch - 28 ports - L3 - Managed
Enclosure Type	Rack-mountable 1U
Subtype	Gigabit Ethernet
Ports	24 x 10/100/1000 (PoE) + 4 x 1 Gigabit / 10 Gigabit SFP+
Power Over Ethernet (PoE)	PoE
PoE Budget	195 W
Performance	Switching capacity: 128 Gbps Throughput: 95.23 Mpps Latency (1 Gbps): 2.4 µs Latency (10 Gbps): 1.3 µs
Capacity	Link aggregation ports: 8 IPv4 routes (static): 32 VLANs supported: 256 Access Control Entries (ACEs) per ACL: 480 Packet buffer size: 1.5 MB
MAC Address Table Size	16000 entries
Jumbo Frame Support	9216 bytes
Routing Protocol	Static IP routing
Remote Management Protocol	SNMP 1, RMON, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, RADIUS
Encryption Algorithm	SSL
Authentication Method	RADIUS
Features	Flow control, DHCP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, IPv6 support, half duplex mode, full duplex mode, STP support, MSTP support, ACL support, QoS, TPM, LLDP support, LACP, Energy Efficient Ethernet, CoS, BPDU Filter, PoE Class 4
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.2af
Processor	1 x ARM: 800 MHz
RAM	512 MB SDRAM
Flash Memory	256 MB
Status Indicators	Port status, power, PoE
Expansion / Connectivity
Interfaces	24 x 10/100/1000 Base-T RJ-45 PoE - 195 W 4 x 1/10Gbit LAN SFP+
Power
Power Device	Internal power supply
Voltage Required	AC 100-127/200-240 V (50/60 Hz)
Power Consumption Operational	234 Watt
Miscellaneous
MTBF	76 years
Compliant Standards	VCCI, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1, EN 60825-1, CNS 13438, EN 55024:2010, FCC CFR47 Part 15 A, ICES-003 issue 6 Class A, UL 62368-1 Second Edition, CISPR 32 Class A, EN 62368-1:2014, EN 55032:2015+AC:2016, CISPR 35, SSL, IEC 62368-1: 2014 Second Edition, EN 55035:2017
Dimensions & Weight
Width	44.25 cm
Depth	26.47 cm
Height	4.39 cm
Weight	3.49 kg
Manufacturer Warranty
Service & Support	Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature	0 °C
Max Operating Temperature	40 °C
Humidity Range Operating	15 - 95% (40 °C)
Min Storage Temperature	-40 °C
Max Storage Temperature	70 °C
Humidity Range Storage	15 - 95% (60 °C)
