Информираме Ви, че въпреки нашите усилия не можем да гарантираме, че публикуваната информация и снимки не съдържат неточности или грешки, които не могат да бъдат правно основание за претенции.
| Суич, тип | Fixed Port |
| Общ брой портове | 52 |
| Основни портове, тип | 48x10/100/1000Base-T |
| Power Over Ethernet (PoE) | IEEE 802.3at PoE+ (up to 30W per port), Perpetual PoE, Fast PoE; Available PoE Power: 740W* (Default primary power supply - PWR-C5-1KWAC), 1440W* (Optional secondary power supply - PWR-C5-1KWAC), *Limited by port number and port rating |
| Uplink портове | 4x10/100/1000Base-T |
| Свободни (10GB) слотове | No |
| Управление | SNMPv1, SNMPv2c, and SNMPv3; RMON I and II standards; Internet Group Management Protocol (IGMP); CLI; TCP; UDP |
| Stackable | Cisco StackWise-80 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200L-STACK-KIT=), Supported stack members: Other C9200L models with same license level (8 Number of members) |
| Fans | Fixed redundant |
| Захранване | Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-1KWAC |
| Routing | Layer 3 Advanced |
| Памет (Flash, RAM) | Flash memory: 4 GB; RAM: 2 GB DRAM |
| Капацитет за маршрутизиране/превключване, Gbps | 104 Gbps |
| Пропускателна способност, Mpps | 154.76 Mpps |
| MAC адреси | 16000 MAC address |
| VLAN (брой, стандарти) | VLAN IDs: 1024; IEEE 802.1Q VLAN |
| QoS | Granular wireless bandwidth management and fair sharing,802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification,Shaped Round Robin (SRR) scheduling,Committed Information Rate (CIR), and eight egress queues per port |
| L2 мрежови стандарти | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x |
| L3 мрежови стандарти | IP unicast routing protocols: Static, Routing Information Protocol Version 1 [RIPv1], and RIPv2, RIPng, Open Shortest Path First [OSPF] |
| IPv6 functionality | IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance; IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting |
| Сигурност | Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems |
| Размери (Ш, Д, В), mm | 445 x 288 x 44 |
| Опция за монтаж | Rackmount |
| Други | Задължителен е минимум 3-годишен лиценз DNA Essentials. |
| Приложение | за бизнеса |
| Атрибут | Стойност |
|---|---|
| Суич, тип | Fixed Port |
| Device Type | Switch - 48 ports - L3 - stackable |
| Общ брой портове | 52 |
| Enclosure Type | Rack-mountable |
| Основни портове, тип | 10/100/1000Base-T |
| Subtype | Gigabit Ethernet |
| Power Over Ethernet (PoE) | PoE+ |
| Ports | 48 x 10/100/1000 (PoE+) + 4 x Gigabit SFP (uplink) |
| Свободни (10GB) слотове | No |
| Performance | Stacking bandwidth: 80 Gbps Switching capacity: 104 Gbps Forwarding rate: 154.76 Mpps |
| Управление | Yes |
| Управление | Yes |
| Capacity | Virtual networks: 1 IPv4 routes: 11000 IPv4 routing table entries: 3000 IPv6 routing table entries: 1500 Multicast scale: 1000 ACL scale entries: 1500 FNF entries: 16000 VLANs supported |
| Stackable | Optional module |
| MAC Address Table Size | 16000 entries |
| Fans | Да |
| Jumbo Frame Support | 9198 bytes |
| Захранване | Redundant |
| Захранване | Redundant |
| Routing Protocol | OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, PIM-SSM, policy-based routing (PBR), RIPng, MSTP |
| Routing | Advanced |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF |
| Опция за монтаж | Rackmount |
| Uplink портове | 4x10/100/1000Base-T |
| Подкатегория | Switches |
| Приложение | за бизнеса |
| Features | Quality of Service (QoS), Cisco StackWise Technology, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), PXE support, Remote Switch Port Analyzer (RSPAN), NetFlow, Energy Efficient Ethernet, Management Information Base (MIB), Class of S |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 1 |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at |
| RAM | 2 GB |
| Flash Memory | 4 GB |
| Interfaces | 48 x 1000Base-T RJ-45 PoE+ - 30 W 4 x 1000Base-X SFP uplink 1 x network stack device 1 x management (LAN) RJ-45 1 x console RJ-45 |
| Power Device | Internal power supply - hot-plug |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| MTBF | 347,760 hours |
| Width | 44.5 cm |
| Depth | 4.4 cm |
| Height | 28.8 cm |
| Weight | 4.35 kg |
| Service & Support | Limited warranty - advance parts replacement - lifetime - response time: next business day |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 90% (non-condensing) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 1440 W |
| Тегло | 5.00кг |
