- CISCO
Цена
5252.83 лв.
с ДДС
* ВЪНШЕН ДОСТАВЧИК
Безплатна Доставка
* - Стоката е в склад на официалния вносител на марката за България. Времето за доставка е обикновено от 1 до 3 работни дни. Възможно е към момента на завършване на поръчката, продукта да е вече изчерпан. В случай на изчерпана наличност ще се свържем с Вас
Информираме Ви, че въпреки нашите усилия не можем да гарантираме, че публикуваната информация и снимки не съдържат неточности или грешки, които не могат да бъдат правно основание за претенции.
| Суич, тип | Fixed Port |
| Общ брой портове | 24 |
| Основни портове, тип | 24x10/100/1000Base-T |
| Power Over Ethernet (PoE) | No |
| Свободни (10GB) слотове | 1 open module slot: Support four optional uplink modules (C9300-NM-4G, C9300-NM-8X, C9300-NM-2Q, C9300-NM-4M). Also supported 3850 network modules (C3850-NM-4-1G, C3850-NM-2-10G, C3850-NM-4-10G). |
| Управление | SNMPv1, SNMPv2c, and SNMPv3; RMON I and II standards; Internet Group Management Protocol (IGMP); CLI; TCP; UDP |
| Stackable | Cisco StackWise-480 stacking ports: copper-based Cisco StackWise cabling |
| Fans | Three field-replaceable fans |
| Захранване | Dual redundant power supplies, Default power supply: PWR-C1-350WAC |
| Routing | Layer 3 Advanced |
| Памет (Flash, RAM) | Flash memory: 16 GB; RAM: 8 GB DRAM |
| Капацитет за маршрутизиране/превключване, Gbps | 208 Gbps |
| Пропускателна способност, Mpps | 154.76 Mpps |
| MAC адреси | 32000 MAC address table size |
| VLAN (брой, стандарти) | VLAN IDs: 4000; IEEE 802.1Q VLAN |
| QoS | Granular wireless bandwidth management and fair sharing,802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification,Shaped Round Robin (SRR) scheduling,Committed Information Rate (CIR), and eight egress queues per port |
| L2 мрежови стандарти | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x, IEEE 802.1AE |
| L3 мрежови стандарти | IP unicast routing protocols: Static, Routing Information Protocol Version 1 [RIPv1], and RIPv2, RIPng, Open Shortest Path First [OSPF] |
| IPv6 functionality | IPv6 routing; IPv6 addressing; Dual-stack support for IPv4/IPv6 and dynamic hardware forwarding table allocations, for ease of IPv4-to-IPv6 migration; IPv6 support in hardware, providing wire-rate forwarding for IPv6 networks |
| Сигурност | Encrypted Traffic Analytics (ETA), AES-256 MACsec encryption, Trustworthy systems built with Cisco Trust Anchor Technologies (Image signing, Secure Boot, Cisco Trust Anchor module) |
| Размери (Ш, Д, В), mm | 445 x 445 x 44 |
| Опция за монтаж | Rackmount |
| Други | Задължителен е минимум 3-годишен лиценз DNA Essentials. |
| Приложение | за бизнеса |
| Атрибут | Стойност |
|---|---|
| Суич, тип | Fixed Port |
| Device Type | Switch - 24 ports - Managed - stackable |
| Общ брой портове | 24 |
| Enclosure Type | Rack-mountable 1U |
| Основни портове, тип | 10/100/1000Base-T |
| Subtype | Gigabit Ethernet |
| Power Over Ethernet (PoE) | No |
| Ports | 24 x 10/100/1000 |
| Свободни (10GB) слотове | 1 |
| Performance | Switching capacity: 128 Gbps Stacking bandwidth: 480 Gbps Forwarding rate: 154.76 Mpps |
| Управление | Yes |
| Управление | Yes |
| Capacity | IPv4 routing table entries: 32000 IPv6 routing table entries: 16000 Flexible NetFlow entries: 64000 VLAN IDs: 4000 Switched virtual interfaces (SVIs): 2000 |
| Stackable | Yes |
| MAC Address Table Size | 32000 entries |
| Fans | Да |
| Jumbo Frame Support | 9198 bytes |
| Захранване | Redundant |
| Захранване | Redundant |
| Routing Protocol | OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng |
| Routing | Advanced |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF |
| Опция за монтаж | Rackmount |
| Encryption Algorithm | 128-bit AES |
| Подкатегория | Switches |
| Приложение | за бизнеса |
| Features | Trunking, full duplex mode, Weighted Random Early Detection (WRED), Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Management Information Base (MIB), Cisco StackWise- |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s |
| Compliant Standards | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Cla |
| RAM | 8 GB |
| Flash Memory | 16 GB |
| Status Indicators | Status |
| Interfaces | 48 x 1000Base-T RJ-45 1 x USB 2.0 |
| Expansion Slots | 1 (total) / 1 (free) x Expansion Slot |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Power Provided | 350 Watt |
| Voltage Required | AC 120/230 V (50 - 60 Hz) |
| MTBF | 314,790 hours |
| OS Required | Cisco IOS Universal |
| Width | 44.5 cm |
| Depth | 44.5 cm |
| Height | 4.4 cm |
| Weight | 7.27 kg |
| Service & Support | Limited warranty - replacement - lifetime - response time: next business day Technical support - consulting - 90 days |
| Min Operating Temperature | -5 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 90% (non-condensing) |
| Тегло | 8.00кг |
